TECHNICAL DATA TD-19
Torques:
[∅ mm]
[Nm]
Front axle nut 12 55
Rear axle nut 14 120
Front fork upper fixing --- ---
Front fork lower fixing 10 20 / 30
Shock absorber upper fixing 10 30
Shock absorber lower fixing 8 25
Steering nut 10 50
Engine mounting screw 10 50
12 55
Crankcase 6 10
Cylinder head 7 15
Flywheel 10 35
Drain plug gearbox 8 15
Exhaust pipe 6 10
Silencer 8 30
Standard torque for 12 60
screws and nuts without 10 40
special function 8 25
6 12
5 4
Spark plug 14 15
Electrical assy:
Battery charging voltage
(Battery fully charged)
14 +
0,5 [V]
Battery charging current
(Battery empty)
0,4 [A]
Fuse 8 [A]
Bulb headlamp 35 / 35 (S2) [W]
License plate illumination --- [W]
Bulb rear- and stop lamp 21 / 5 [W]
Bulb winker 10 [W]
Ignition pulse generator 500 + 50
[Ω]
Ignition coil primary 0,3 – 0,5
[Ω]
Ignition coil secondary 1,4 + 10%
[kΩ]
Spark plug connector 5
[kΩ]
Spark plug BR7ES --
Spark plug gap 0,7 – 0,8 [mm]
Spark gap min. 6 [mm]
Ignition point 13 / 2000 [°/min
-1
]
