CRANK DRIVE / CRANKCASE / CRANKSHAFT CR-10
Clamp the crankshaft between two test
prods or place it on a vee-block for
measuring.
Measure the lateral runout with the aid of
two dial gauges.
The actual value is the half of
the measured value.
Maxiumum lateral runout: 0.1 mm
Check the crankshaft bearing clearance.
In case of noises or abnormal clearance
the bearings shall be replaced.
