Table of Contents
Specifications 2
General Safety 3
Icon Library 4-5
First Time Start Up 6
Theory of Operation 7-8
Other Functions 9
Maintenance and Care 10-11
Parts List and Warranty 11
A/C Database End-User License Agreement 12-13
Unit Consists Of:
Specifications
•
FX3030
Automotive Refrigerant Management Center
• Low and High side service hoses R-134a and R1234yf
• Low and High side R-134a and R1234yf Service Couplings
• Tank Refill Adapters - Two for R134a and one for R1234yf.
• 41 cubic Inch CPS filter drier (Replacement part number FX3030X1)
• 1 lb (454 gram) check weight
• Operation manual
• 1 Roll 2.25” x 50” Thermal Paper
• Built-in Refrigerant Identifier
• 50lb DOT Tank/Filter and Hose Sets for R134a (Installed) and R1234yf
End user to provide:
• Refrigerant oil/dye injection system
• Refrigerant
FX3030 Specifications
Power 115V 60Hz 1Ph
Compressor 2/3 HP Twin Cylinder Oil-less
Vacuum Pump 50 Micron Rated 6 CFM
Gauges 3.5” Low side, 30 in/Hg to 250 psi; High Side, 0 to 600 psi
Hoses 120” barrier type
Refrigerant R-134a | R1234yf
Storage Tank Assemblies 2 x 50 lb DOT with processor controlled heat band
Display 7” Touch Screen with 256 color graphical display
Printer 2.25” Thermal Printer
Construction
Sheet metal frame adorned by injection and rotary molded plastic. Two handle bars, 4” front casters and 10” foam-filled rear tires
for exceptional maneuverability
