MODEL CX201 – 10” TABLE SAW WITH 50” RAILS & EXTENSION TABLE
As part of the growing line of Craftex woodworking equipment, we are proud to offer the
CX201 a 10” Table Saw with 50” Rails, Riving Knife and Extension Table. The Craftex name
guarantees Craft Excellence. By following the instructions and procedures laid out in this user
manual, you will receive years of excellent service and satisfaction. The CX201 is a
professional tool and like all power tools, proper care and safety procedures should be
adhered to.
Motor ..............................................3-HP, 220-V, 12.8 Amp, Single Phase TEFC Motor
Drive System ..................................Triple “V” Belt Drive
Blade Guard ...................................Riving Knife, CSA Approved & UL897 Compliant
Miter Gauge....................................T-Slot Miter Gauge
Rip Fence .......................................“T” Type Heavy Duty Rip Fence (Cam Lever) w/Optical Cursor
Fence Size......................................Length 48” x Width 4-1/8” x Height 2-1/2”
Table Size.......................................Length 73-3/4” x Width 27” (with Extension Wings)
Floor to Table Height......................34”
Maximum Blade Diameter ..............10”
Riving Knife/Spreader Thickness....0.1”
Arbor Size.......................................5/8”
Arbor Speed ...................................4300 RPM
Maximum Width of Dado ................13/16”
Maximum Depth of Cut @ 90°........3-1/8”
Maximum Depth of Cut @ 45°........2-3/16”
Maximum Rip to Right of Blade ......50”
Maximum Rip to Left of Blade.........12”
Dust Collection Ports......................One 4” Port
Dimensions.....................................Length 82” x Width 41” x Height 40”
Approximate Weight .......................590 lbs.
CX201–1” Table Saw
FEATURES
