Craftex CX503 - Parts List

17
REF# DESCRIPTION QTY
1
CUP HEAD SCREW M4X6 8
2
LEFT COVER 1
3
WORK TABLE 1
4
FIXATION BOARD OF WORK
TABLE
1
5
FLAT ASHERΦ8X28 1
6
HEXAGONSOCKET
COUNTERSUNK HEAD SCREW
8*10
2
7
HEXAGONSOCKET
COUNTERSUNK HEAD SCREW
8*16
4
8
U-SUPPORT 1
9
BODY 1
10
DUST RECEIVER 1
11
DRIVEN WHEEL 1
12
STAR GRIP SCREW 2
13
SPRING 2
14
POSITION TUBE 2
15
FLAT FASHER Φ8 3
16
SELF-LOCKING NUT M8 2
17
ELASTIC WASHERΦ8 9
18
DRIVEN WHEEL GUIDE 1
19
COLUMNAR PINΦ6X50 1
20
BOLT M8X20 1
21
SHAFT BLOCK 1
22
HAND WHEEL 1
23
HEXAGONAL SOCKET SCREW
M6X30
1
24
SPRING 1
25
RETAINING RING Φ47 2
26
BEARING 204 2
27
DRIVEN WHEEL SHAFT 1
28
FLAT WASHER Φ8 6
29
BOLT M8X18 2
30
CUP HEAD SCREW M4X10 2
31
FLAT WASHER Φ4 2
32
PERSPECTIVE PLATE 1
33
COLLECTING BOARD 2
REF# DESCRIPTION QTY
34
CUP HEAD SCREW M6X50 1
35
FLAT WASHER Φ6 2
36
BOLT M8X12 2
37
FENCE EXTENSIONS 1
38
SELF-LOCKINGNUTM6 1
39
NUT M4 2
40
MOTOR 1
41
BOLT M8X18 4
42
HAND BALL 1
43
SAFETY COVER 1
44
TOP TABLE 1
45
RIGHT COVER 1
46
SIDE FENCE 1
47
PROPECT TUBE 1
48
PIN 3X20 1
49
SPRING 1
50
HAND BAR 1
51
BASE 1
52
WASHER 1
53
LOCK KNOB 1
54
LOCK SHAFT 1
55
SCREW 6X16 1
56
HEXAGONAL SOCKET SCREW
M5X20
1
57
SAND BELT 1
58
BIG WASHER Φ32 1
59
DRIVE WHEEL 1
60
CUP HEAD SCREW M8X20 2
61
ELASTIC WASHER Φ8 2
62
BOLT M8X12 3
63
HAND BAR COLLECTING ROD 1
64
HANDLE 1
65
BLACK LEAD PLATE 1
66
HINGE 4
67
CUP HEAD SCREW M4X6 16
68
SPRING PLATE 1
CX503 PARTS LIST
