5
MODEL CX801 HEAVY DUTY BENCH TOP LATHE
As part of the growing line of Craftex woodworking equipment, we are proud to offer CX801
a Heavy Duty Bench Top Lathe. By following the instructions and procedures laid out in this
owner’s manual, you will receive years of excellent service and satisfaction. The CX801 is
a professional tool and like all power tools, proper care and safety procedures should be
adhered to.
Main Motor..........................................Single Phase 1/2 HP, 110V, 60 HZ, 6Amps
Speed..................................................1725 RPM
Swing Over Bed..................................10”(254mm)
Swing Over Tool Rest (Base)..............7-1/2”(190mm)
Distance Between Center....................15 ½” (394mm)
Tailstock Travel....................................3 ¼” (83mm)
Spindle Size.........................................7-51/64” x 1-7/8”
Spindle TPI..........................................1” x 8 TPI
Spindle Taper.......................................MT2
Spindle Center......................................5”(127mm)
Tailstock Taper.....................................MT2
Tailstock Center....................................5”(127mm)
Number of Spindle Speeds...................6
Spindle Speed Ranges.........................480, 1270, 1960, 2730, 3327, 4023 RPM
Bed Width..............................................8-3/16”(208mm)
Faceplate Size.......................................3” (76mm)
Bed Construction...................................Cast Iron
Headstock Construction Cast................Cast Iron & Steel
Tailstock Construction Cast...................Cast Iron & Steel
Bearings.................................................Shielded and Lubricated
Approx. Weight......................................105 lbs. (45 Kg)
CX801 BENCHTOP
LATHE
FEATURES
