4. Tipthesnowthrowerbackto theoperatingpositionandpullthestarter
handleafewtimestoseeif it isdifficultto pull.
5. If thestarterisdifficultto pull,removethesparkplugandpullthehandle
severaltimestoensurethat anyoil trappedintheengineheadisremoved.
Oilmaycomeout of the sparkplug holewhen it isremovedand the starter
handleispulled.
6. Inspectthesparkplug.If it iswet,cleanoff anyo11beforere-installing.
ControlCable
Asaresultofboththecontrolcableandtheaugerdrivebeltstretchingduetowear,
periodicadjustmentsmaybenecessary.Iftheaugerseemstohesitatewhenrotating,
proceedasfollows:
Theupperholeinthecontrolhandleprovidesforan adjustmentin cabletension.
Toadjust,disconnecttheendofcontrolcablefromthebottomholeinthecontrol
handleandreinsertit intheupperhole.Insertthecablefromtheoutsideasshown
in Figure21.
F
/
/
ControlCable
Figure21
Testthesnowthrowerto seeif thereisanoticeabledifference.Ifafterthe
adjustmenttothecontrolcabletheaugerstill hesitateswhenrotating,seeBelt
Replacementforinstructionsonreplacingthebelt.
ChuteAssembly
RefertotheAssemblysectionforinstructionsonadjustingthechuteassembly.
AugerDriveBelt Replacement
1. Runthesnowthroweruntil thefueltankisempty.
2. Pulltherecoilstarterhandleuntil resistanceisfelt.Thentip thesnow
throwerbackuntil it restsonthehandles.
3. Slideaboardupthroughtheaugerandthroughthechutetosecurethe
augerinplace.
4. Removethebeltcoverby removingthetwohexwasherscrewsandonehex
lockscrewthatsecureit totheframe.SeeFigure22.
HexLockScrew
HexWasherScre_
Figure22
Removetheflangenutthat securestheaugerpulleyto theaugershaft.See
Figure23.
/
\\
Ang_
An
Figure23
FlangeNut
J
6. Removetheaugerpulleyandthebelt.
17
