REPAIR PARTS LIST FOR MODELS 486.242221, 486.242241
42" HIGH PERFORMANCE LAWNSWEEPER
REF PART
NO.
qTY DESCRIPTION
1 46776 1 HitchTube,R.H.
2 46777 1 HitchTube,L.H.
3 65885 1 HousingAssembly
4 49102 4 Screw,#12x1/2"HexHead
5 142 1 Pin,Cotter1/8"x3/4"Lg.
6 68202 1 HeightAdjustmentTubeAss'y.
7 43070 1 Washer,3/8"Flat
8 C-9M5732 8 Rivet,Pop
9 43086 4 LockWasher,5/16"
10 43080 4 Bolt,Carriage5/16-18x3/4"
11 62489 2 BrushBushingAss'y.
12 44232 2 Ball Bearing
13 1629-56 2 Retainer,DustCover
14 25847 1 Brush Shaft
15 46780 4 Brush,42"
16 43012 8 Bolt,Hex1/4-20x3/4"Lg.
17 47189 16 Nut,Nylock1/4-20Thread
18 23580 4 Retainer,Brush(Double)
19 23581 8 Retainer,Brush(Single)
20 44008 2 Washer,Flat1-1/8"x.78"x.025"
21 62490 2 Sprocket/Gear
22 23573 2 DustCover
23 47046 2 DowelPin(Drive)
24 43655 2 Ring,Retaining3/4"
25 716-0106 2 Ring,Retaining.594"
26 40001 14 Washer,Shim1-1/8"x.594"x.025"
27 43182 4 Bolt,Hex5/16-18x3/4"Lg.
28 141 6 Washer,Flat1-1/2"x.375"x.062"
29 1540-31 4 Washer,Flat.78"x1.25"x.06"
30 1038 2 Nut,Nylock3/8-24Thread
31 2674-32 2 HubCap
32 1650-1 2 Ring,Retaining(E-type)
33 43932 2 Bolt,Hex3/8-24x3-1/2"Lg.
34 23400 2 Bushing, Spacer
35 43890 1 Sprocket,RatchetR.H.
36 43889 1 Sprocket,RatchetL.H.(notshown)
37 44137 4 Washer,1/2"x1"x.02"
38 44542 2 Chain,Roller
39 43661 4 Bolt,Hex1/4-20x1"Lg.
REF PART
NO.
qTY DESCRIPTION
40 65667 1 Housing,WheelDriveAss'y.L.H.
41 65668 1 Housing,WheelDriveAss'y.R.H.
42 49765 2 Tube,UpperHopperFrame
43 47477 2 Tube,RearHopperFrame
44 48726 2 Tube,LowerHopperFrame
45 24189 1 Strap, Bag Frame
46 25813 2 Strap,HopperSupport
47 43737 1 HopperRope
48 49768 1 HopperBag
49 24979 1 Strap,HeightAdjustment
50 23687 1 Bracket,Hitch
51 24192 1 Bracket,Hitch(Straight)
52 23331 4 HopperMountClamp
53 49766 2 Tube,BagArm
54 46823 1 PivotRod,HopperBag
55 44985 2 Wheel&TireAss'y.(withbearings)
56 45088 4 Wheel Bearing
57 46782 2 Bolt,Hex5/16-18x3"Lg.
58 43224 3 Bolt,Hex5/16-18x2-1/4"Lg.
59 47810 12 Nut,Nylock5/16-18Thread
60 23625 1 Spacer,.38"x.62"x.27"L
61 43720 1 Knob,Wing5/16-18Thread
62 44326 1 Bolt,Carriage5/16-18x1"Lg.
63 43081 2 Washer,Flat5/16"Std.Wrt.
64 43084 3 Bolt,Hex5/16-18x1-3/4"Lg.
65 43943 1 Grip,HeightAdjust
66 44732 1 Washer,ToothLock5/16"
67 49493 1 Pin,Hitch
68 23368 2 Tube,HitchSpacer
69 43343 1 HairpinCotter,1/8"
70 44917 2 Palnut,3/8"
71 43978 4 CurvedHeadBolt,1/4-20x1"
72 48365 4 Pin,Clevis1/4"x1-1/8"
73 48366 2 Pin,Clevis3/8"x1/2"
74 44481 2 Cap,Vinyl
75 43055 8 HairpinCotter,3/32"#3
76 46867 2 Pin,Clevis1/4"x1-1/2"Lg.
77 44230 1 Spring,HitchPin
40734 1 OwnersManual
