Craftsman 486.242221 - Accessories And Attachments; Carton Contents

3
CARTON CONTENTS (LoosePartsinCarton)
11.UpperHopperTube(2)
12.LowerHopperTube(2)
13.PivotRod
14.HopperSupportStrap(2)
15.BagFrameStrap
16.BrushAssembly(2)
1. SweeperHousingAssembly
2. BagArmTube(2)
3. HitchTube,L.H.(LeftHand)
4. HitchBracketAssembly
5. HitchBracket,Bent
1
2
3
5
6
7
2
8
9
4
10
11
13
14
10
12
11
12
16
15
ACCESSORIES AND ATTACHMENTS
TheFrontMountDethatcher,Model486.24219attaches
tothelawnsweepertohelploosenandremovedead
grass and thatch from the lawn while sweeping.
These accessories were available when the unit was purchased. They are also available at most Sears retail
outlets and service centers. Most Sears stores can order repair parts for you when you provide the model
numbers of your tractor and sweeper
6. HeightAdjustmentStrap
7. HitchTube,R.H.(RightHand)
8. Rope
9. HopperBag
10.RearHopperTube(2)
