STEP 17 - ASSEMBLE HOPPER CLAMPS
• Assembletwohoppermountclamps(T)overthehole
inthemiddleofeachupperhoppertubeusingtwo
carriagebolts(F)andtwonylocknuts(I).Tightenonly
ngertight.Seegure17.
• Foldthebagapsaroundthelowerhoppertubesand
attachtothebagbottomusingthesnaps.Seegure
16.
FIGURE 16
STEP 16 - ATTACH BAG BOTTOM
• Insertthebagframestrapintothestitchedsleeveat
thefrontedgeofthebagbottom.Seegure14.
FIGURE 15
FIGURE 17
CLEVIS PIN (O)
HAIR COTTER
PIN (S)
BAG FRAME STRAP
SNAP
FLAP
BAG FRAME STRAP
STITCHED
SLEEVE
• Assemblethebagframestraptotheholesinthe
lowerhoppertubesusingtwoclevispins(O)andhair
cotterpins(S).Seegure15.
FIGURE 14
5/16" x 3/4"
CARRIAGE
BOLT (F)
5/16" NYLOCK
NUT (I)
HOPPER
MOUNT
CLAMP (T)
UPPER
HOPPER
TUBE
