PARTS LIST
Craftsman Model C459.60310
Ref.
No.
Part No. Description
1 710-04482 Hex Flange Bolt, 3/8-16 x .875
2 710-04484 Screw, Hd. Tapp, 5/16-18 x .75
3 712-3004A Flange Lock Nut, 5/16-18
4 925-05013 Seat Safety Switch
5 757- 04144 Seat
6 926-0154 Push Mount Cable Tie
7 732-04035 Spring, Compress., 1.28 x 3.125
8 732-04563 Spring, Compress., .68 x 1.065 x .055
9 938-0296 Shoulder Screw, 5/16-18 x .437 x .268
10 783-06050 Seat Adjustment Lever
11 783-06088-0637 Seat Pivot Bracket
12 783-06448 Switch Retainer Clip
13 783-06840-0637 Seat Mounting Bracket
14 735-04047 Rubber Foot Pad, LH
735-04048 Rubber Foot Pad, RH
15 726-3046 Ratchet Clip, .250
16 710-05070 Tap Screw, 1/4-20 x .5
17 710-0599 Screw Pan Torx Head, 1/4-20 x .500
18 731-04591A Cup Holder
19 783-04587D-4044 Fender
20 783-04843-0637 Lift Adjuster Bracket
21 710 - 0134 Carriage Screw, 1/4-20 x .62
— 725-05277 Seat Jumper Harness (not shown)
