PARTS LIST
Craftsman Engine Model 31P677-0912-G5 For Model C459.60310
Ref.
No.
Part No. Description
306 796006 Shield-Cylinder
307 691693 Screw (Cylinder Shield)
309 693551 Motor-Starter
310 690323 Screw (Starter Motor)
324 796308 Screen/Cup Assembly
333 799650 Armature-Magneto
334 691061 Screw (Magneto Armature)
337 491055s Plug-Spark
358 796187 Gasket Set-Engine
404 691691 Washer (Governor Crank)
415 794129 Plug (Cover/Retainer)
415A 690283 Plug (Intake Manifold)
431 797901 Elbow-Intake
445 796031 Filter-Air Cleaner Cartridge
462 691261 Washer (Starter Cable)
474 696459 Alternator
503 691532 Strap-Starter
505 691251 Nut (Governor Control Lever)
510 693699 Drive-Starter
513 692024 Clutch-Drive
523 699908 Dipstick
524 691032 Seal-Dipstick Tube
525 697184 Tube - Dipstick
552 697144 Bushing-Governor Crank
562 691119 Bolt (Governor Control Lever)
579 691029 Nut (Starter Cable)
584 794682 Cover-Breather Passage
585 697109 Gasket-Breather Passage
601 791850 Hose-Clamp (Green)
614 691620 Pin-Cotter (Governor Crank)
616 692012 Crank-Governor
617 692138 Seal-O Ring (Intake Manifold) (Red)
633 699813
Seal-Choke/Throttle Shaft (Choke
Shaft)
634 698779 Spring/Seal Assembly (Choke Shaft)
635 691909 Boot-Spark Plug
654 690958 Nut (Carburetor)
684 697157 Screw (Breather Passage Cover)
Ref.
No.
Part No. Description
691 692407 Seal-Governor Shaft
697 791680 Screw (Drive Cap)
718 690959 Pin-Locating
729 691224 Clip-Wire
741 697128 Gear-Timing
750 790832 Screw (Oil Pump Cover)
757 793242 Link-Counterweight
758 793763 Counterweight
759 697392 Pin-Counterweight
783 693713 Gear-Pinion
789 698329 Harness-Wiring
797 693167 Nut (Brush Retainer)
801 691283 Cap-Drive
802 691286 Cap-End
830 691095 Stud-Rocker Arm
842 691031 Seal-O Ring (Dipstick)
847 790442 Dipstick/Tube Assembly
850 100106 Sealant-Liquid
851 692424 Terminal-Spark Plug
868 690968 Seal-Valve
877 790544 Wire/Connector-Alternator
883 692236 Gasket-Exhaust
914 697551 Screw (Rocker Cover)
943 690589 Seal-O Ring (Oil Pump Cover)
947 699915 Solenoid-Fuel
964 799159 Cap-Connector
965 499613 Cover-Oil Pump
968 797902 Cover-Air Cleaner
975 699502 Bowl-Float
987 698777 Seal-Throttle Shaft
1005 796083 Fan-Flywheel
1017 796981 Screen-Oil Pump
1022 272475s Gasket-Rocker Cover
1023 797421 Cover-Rocker
1024 794644 Pump-Oil
1026 692003 Rod-Push (Intake)
1026A 69 2011 Rod-Push (Exhaust)
