Craftsman C459.60310 - Page 50

50
PARTS LIST
Craftsman Engine Model 31P677-0912-G5 For Model C459.60310
Ref.
No.
Part No. Description
1027 492932s Filter-Oil
1029 691751 Arm-Rocker
1034 690822 Guide-Push Rod
1036
Label-Emissions (Available from a
Briggs & Stratton Authorized Dealer)
1040 699852 Plate-Trim
1044 698139 Screw (Flywheel)
1051 691265 Ring-Retaining
1054 280275 Tie-Cable
1058 276344 Operator’s Manual
1059 698516 Kit-Screw/Washer (Alternator)
1070 690363 Screw (Flywheel Fan)
1090 691293 Retainer-Brush
1091 691333 Cap-Limiter
1095 794152 Gasket Set-Valve
1119 691183 Screw (Alternator)
1127 695407 Screw (Float Bowl)
1263 697124 Reed-Breather
1264 697104 Screw (Breather Reed)
1266 691917 Seal-O Ring (Intake Elbow) (Red)
1270 793243 Plug-AVS Counterweight
1329
331877-
3036-G5
Replacement Engine
1330 276781 Repair Manual
Engine Gasket Set Key No. 358
Valve Gasket Set Key No. 1095
Carburetor Overhaul Kit Key No. 121
