57
Section 5.1: User Level Functions
5.1.1 Frequency Output Monitor
The drive frequency can be monitored via Keypad and Multifunction output
terminals.
VIA KEYPAD
User Level [Function No. 1]: Displays Drive Frequency Output
The Keypad displays the drive frequency output to the motor once the RUN
command is initiated.
When the drive is not in RUN mode, the frequency display indicates the
programmed speed 1 frequency.
VIA FREQUENCY METER TERMINAL (See Section 5.3.14)
5.1.2 Frequency Reference
User Level [Function No. 1] Speed 1 (Factory Default: 10.0 Hz.)
Range: 0.0 – F9 Hz.
SP2 (User Level): Speed 2 (Factory Default: 60.0 Hz.)
Range: 0.0 – F9 Hz.
SP3 (User Level): Speed 3 (Factory Default: 0.0 Hz.)
Range: 0.0 – F9 Hz.
SdS (User Level): Speed Mode Macro (Factory Default: 1: 2 Step Infinitely Vari-
able)
Range: 0: 2 Speed
1: 2 Step Infinitely Variable
2: 3 Speed
3: 3 Step Infinitely Variable
The hoist speed references are set in the User Level. Speed 1 and 2 will be
applied when SdS is set to 0 or 1. Speed 1, 2, and 3 will be applied when SdS is
set to 2 or 3. The value of these speed points will be limited depending on the
value Maximum Frequency set in F9. Generally, the maximum frequency is set
to the maximum motor allowed output speed. The Rated Frequency of Motor
(Base Frequency) F10 is the motor rated speed in constant torque range. This
base frequency value should not be set higher than that of F9.
For frequency settings of F9, F10 and F11 see Section 5.2.6.
