Section 5.2: Service Level Functions
5.2.1 Command Reference (RUN/STOP Selection)
The drive can receive its command sequence (RUN, STOP, FWD, REV), via
external terminals.
F1:
Run/Stop Mode (Factory Default: 1: Terminal)
Range:0: Keypad
1: Terminal
KEYPAD
The JOG function works via the keypad only. See Section 2.2.3 for instructions on
use.
TERMINAL
Each of the sequence commands can be initiated via external controls, such as
pushbuttons.
Table 5.2.1: Drive Input Terminals
slanimreTtupnIdraoBlortnoCevirDdraCecafretnI
xF
dnammoCnoitceriDdrawroF/pU
.gnikniSCDV42.lanimreT
F
dnammoCnoitceriDdrawroF/pU
.gnicruoSCAV021.lanimreT
xR
dnammoCnoitceriDesreveR/nwoD
.gnikniSCDV42.lanimreT
R
dnammoCnoitceriDesreveR/nwoD
.gnicruoSCAV021.lanimreT
TSR.gnikniSCDV42.teseRteseRtluaF
1P.gnikniSCDV42tupnInoitcnuF-itluM2 .gnicruoSCAV021tupnInoitcnuF-itluM
2P.gnikniSCDV42tupnInoitcnuF-itluM3 .gnicruoSCAV021tupnInoitcnuF-itluM
3P.gnikniSCDV42tupnInoitcnuF-itluMP .gnicruoSCAV021tupnInoitcnuF-itluM
MC
gnikniSCDV42roflanimreTnommoC
.stupnI
C
gnicruoSCAV021roflanimreTnommoC
stupnI
5.2.2 Accel / Decel Patterns
F2: Acceleration Pattern (Factory Default: 1: S Curve)
Range: 0: Linear
1: S Curve
F3: Deceleration Pattern (Factory Default: 0: Linear)
Range: 0: Linear
1: S Curve
These values are set with Motion Definition Macro, see Table 2.3.1. The user can
select different acceleration and deceleration patterns for smoother hoist or traverse
ramping.
