Model 721 Parts Manual

7210013 7

March, 2000

TABLE 4. MILLENNIA STYLE TRIM - PART 3

INDEX PART NUMBER DESCRIPTION QTY

1572213 RIGHT HAND TRIM - UPPER - A - 21 - GRAY

17212084 RIGHT PANEL - MONETARY - 7 PUSH BUTTON - BLUE

7212083 RIGHT PANEL - MONETARY - 7 PUSH BUTTON - RED

2 1572212 ARRAY - PUSH BUTTON SELECTION 1

3 1572224 SPRING - PUSH BUTTON 21

4 1572223 PLATE - STOP BUTTONS 1

5 1572292 RETAINER - RETURN BUTTON 1

6 1572210 COIN RETURN BUTTON - A - 2 1

7 2302053 SPACER CUP 4

8 1572323 EXTENSION - COIN INSERT 1

9 1472222 COIN BLOCK (PRESENT ONLY WHEN REQUIRED BY LOCATION) 1

10 1572209 COIN INSERT - A - 1 1
