Model 721 Parts Manual
7210013 23
March, 2000
TABLE 12. DELIVERY PAN ASSEMBLY DETAIL
INDEX PART NUMBER DESCRIPTION QTY
7212053 OUTDOOR DELIVERY PAN ASSEMBLY - 38 1
1 1572449 STRIP - THREADED - 38 2
2 1572448 GUARD - DELIVERY DOOR - UPPER - 38 1
3 1572315 SPACER - DELIVERY DOOR 2
4 1572447 CHANNEL ASSEMBLY - 38 - DELIVERY DOOR 1
5 1572053 DOOR - DELIVERY - 38 1
6 7211273 FILLER - FRONT - 38 1
7 1572289 BACK - DELIVERY DOOR - 38 1
8 4112088 GASKET - FOAM (CUT INTO 4 EQUAL - SIZE PIECES) 1
9 1572455 DOOR ASSEMBLY - PILFERAGE - 38" 1
10 7212057 WELD ASSEMBLY - REAR DOOR 38 1
11 1572452 SLEEVE - PILFER DOOR - L.H. 1
12 1572416 SLEEVE - DELIVERY DOOR 2
13 1572353 ARM ASSEMBLY - SPRING ASSIST 1
14 1572423 ACTUATOR ASSEMBLY. - SPRING ASSIST 1
15 1572420 SPRING 1
16 1572418 SLEEVE - PILFER & REAR DR. - L.H. 1
17 1572421 ANCHOR - SPRING 1
18 1572370 ARM - DOOR CLOSED TRIP 1
19 4302319 SWITCH - LEVER - 1 7/8 1
20 4302316 FASTENER - TWIN TYPE 1
21 7212069 SIDE PLATE ASSEMBLY - RH 1
22 1572229 FILLER - LEFT HAND 1
23 1572301 CHANNEL & STUD ASSEMBLY - L.H. 1
24 7212054 WELD ASSEMBLY - DEL PAN ASSEMBLY 38 1
25 7212067 SIDE PLATE ASSEMBLY - LH 1
26 1572417 SLEEVE - PILFER & REAR DR. - R.H. 2
27 7212060 OUTDOOR LINKAGE ASSEMBLY - RH 1
28 7212038 TRIM FILLER SUPPORT ASSEMBLY 1
29 1572230 FILLER - RIGHT HAND 1
30 1572300 CHANNEL & STUD ASSEMBLY - R.H. 1
31 1412058 TAPE VINYL FOAM 3
