Model 721 Parts Manual
7210013 25
March, 2000
TABLE 13. INNER DOOR ASSEMBLY
INDEX PART NUMBER DESCRIPTION QTY
7212036 INNER DOOR ASSEMBLY 1
1 7212037 FRAME ASSEMBLY - INNER DOOR 1
2 1401110 SWITCH 1
3 7211260 BRACKET,SWITCH - INNER DOOR 1
4 7211259 CHANNEL,MTG. - SWITCH 1
5 7212047 HANDLE - INNER DOOR 1
6 7212044 RETAINER PLATE ASSEMBLY 2
7 7212071 LATCH PLATE & LEVER ASSEMBLY 1
8 9900425 RETAINING RING REINF E TYP.250 2
9 4976055 LEVER - LATCH 2
10 5220113 SPRING WASHER .500 X.254 X.006 4
11 7212041 LATCH PLATE ASSEMBLY - PAINTED 2
12 7212051 HINGE BRACKET ASSEMBLY - LOWER 1
13 7212035 BUSHING - HINGE - INNER DOOR 1
14 7212072 BRACKET,HINGE - POST PAINTED 1
15 7211254 POST - HINGE - INNER DOOR 1
16 7212048 TOP HINGE ASSEMBLY - INNER DOOR 1
17 7212031 GASKET - INNER DOOR 1
