Model 721 Parts Manual

7210013 27

March, 2000

TABLE 14. RETRACTABLE DOOR ASSEMBLY

INDEX PART NUMBER DESCRIPTION QTY

7211176

DRIVE MECH ASSEMBLY - RETRACTABLE DOOR - 115 V (SEE

FIGURE 15)

7211350

DRIVE MECH ASSEMBLY - RETRACTABLE DOOR - 230 V (SEE

FIGURE 15)

2 7211224 BRACE - RETRACT.DR RIGHT TRACK 1

3 7211261 BUSHING - RETRACTABLE DOOR FLAP 2

4 7211244 WASHER - NYLON 10

5 7211270 RETR DR FLAP MTG.BRKT ASSEMBLY - RH 1

6 7211168 TRACK - RETRACTABLE DOOR - RIGHT 1

7 7211122 RETRACTABLE DOOR ASSEMBLY 1

8 7211169 TRACK - RETRACTABLE DOOR - LEFT 1

9 7211271 RETR.DR.FLAP MTG BRKT ASSEMBLY - LH 1

10 7211263 RETRACTABLE DOOR FLAP ASSEMBLY 1

11 7211265 EDGING - RETRACTABLE DOOR FLAP RIGHT 1

12 7211266 EDGING - RETRACTABLE DOOR FLAP BOTTOM RIGHT 1

13 7211267 EDGING - RETRACTABLE DOOR FLAP BOTTOM 1

14 7211268 EDGING - RETRACTABLE DOOR FLAP LEFT 1
