Model 721 Parts Manual

7210013 29

March, 2000

TABLE 15. RETRACTABLE DOOR DRIVE MECHANISM ASSEMBLY

INDEX PART NUMBER DESCRIPTION QTY

7211176 DRIVE MECH ASSEMBLY - RETRACTABLE DOOR - 115 V

7211350 DRIVE MECH ASSEMBLY - RETRACTABLE DOOR - 230 V

1 7211177 BRACKET - MOTOR MOUNTING 1

2 7211178 CHANNEL - RIGHT MOTOR MTG BRKT 1

7211175 MOTOR - RETRACTABLE DOOR - 115 V

7211137 MOTOR - RETRACTABLE DOOR - 230 V

4 4407080 COUPLING - MOTOR & DRIVE SHAFT 1

5 3127034 ROLL PIN 1/8 X 13/16 2

6 7211181 DRIVE DISC & STUD ASSEMBLY 1

7 6131066 WASHER 5/8X.265X.048 ZINC/YEL 2

8 9900425 RETAINING RING REINF E TYP.250 1

9 7211184 DRIVE ARM - RETRACTABLE DOOR 1

10 7211180 BUSHING - DRIVE DISC 1

11 2304109 SWITCH ROLLER LEVER V3L - 139 - D8 2

12 7211179 CHANNEL - LEFT MOTOR MTG BRACKET 1

13 7211183 PLATE - RETRACTABLE DOOR SWITCH 1

14 4751060 RETAINER - HARNESS 4
