Model 721 Parts Manual

7210013 31

March, 2000

TABLE 16. FRONT SCREEN AND LOWER FRONT CABINET COMPONENTS

INDEX PART NUMBER DESCRIPTION QTY

1 7211237 DOOR STRIKER ASSSEMBLY 1

2 7211256 BRKT - RH - BUG SCREEN W/STUD 1

3 4273119 GASK"P"SILICONE W/ADHSIVE BACK 43 IN

4 7211255 BRKT - LH - BUG SCREEN W/STUD 1

5 7211147 SCREEN ASSEMBLY - FRONT - FOLDED 1

7211203 WELD ASSEMBLY - LOWER HINGE MTG. - BLACK

17211299 WELD ASSEMBLY - BLUE - LOWER HINGE MTG

7211298 WELD ASSEMBLY - RED LOWER HINGE MTG

7 7211253 SHIM - LOWER HINGE MOUNTING 1
