Model 721 Parts Manual

7210013 33

March, 2000

TABLE 17. FLUORESCENT LIGHT BALLAST AND LAMP HARNESS COVERS

INDEX PART NUMBER DESCRIPTION QTY

1 7211346 CHANNEL - CORNER HARNESS - BALLAST 1

2 7211335 BRACKET - BALLAST MOUNTING 1

4241135 BALLAST ASSEMBLY - CENTER LIGHT - 115 V

4252187 BALLAST ASSEMBLY - 30W - 230V

4 7211337 CHANNEL, HARNESS - HORIZ. LEFT, LOWER 1

5 7211338 CHANNEL, HARNESS - BALLAST, VERT. 1

6 7211339 CHANNEL, HARNESS - HORIZ. LEFT, UPPER 1

7 7211340 CHANNEL, HARNESS - HORIZ. FRONT 1
