Crane 721 - Page 43

To Next Page

To Previous Page

Model 721 Parts Manual

7210013 39

March, 2000

TABLE 20. HORIZONTAL FOAMED WALL COMPONENTS

INDEX PART NUMBER DESCRIPTION QTY

1 7211135 HORIZONTAL WALL ASSEMBLY 1

2 7211166 SEAL - REFRIGERATION MODULE 1

3 7211250 SEAL - BOT LFT/RT FMD HOR WALL M 2

4 7211221 BKT - BOT.RT RR FOMD HOR WAL MTG 1

5 7211219 BKT - BOT.L/R FOMD HOR WALL MTG. 2

6 4614027 SEAL - 1.00 X .87 (CUT INTO TWO PIECES) 1

7 7211158 SEAL - RIGHT REAR - REFRIGERATION 1

8 7211159 SEAL - LEFT REAR - REFRIGERATION 1

9 7211220 BKT - BOT.LT/RR FOMD HOR WAL MTG 1

10 7211251 SEAL - BOT LFT REAR FMD HOR WALL 1

11 7211217 BRKT - L/R FOMD HOR.WAL MNTG 2

12 7211218 BRKT - TOP RR FOMD HOR WALL MTG 1

13 7211252 SEAL - BOT RT REAR FMD HOR WALL 1
