Model 721 Parts Manual

7210013 47

March, 2000

TABLE 24. LIGHT ASSEMBLY DETAIL

INDEX PART NUMBER DESCRIPTION QTY

- 7211347 LIGHT & DIFFUSER ASSEMBLY 2

1 7211186 WELD ASSEMBLY - LIGHT FIXTURE 1

2 7211191 BRACKET - MOUNTING - LIGHT 2

3 4031150 FLUORESCENT LAMP STARTER FS-4 2

4 7211192 DIFFUSER - LIGHT 1

5 4242016 INSULATOR - LIGHT SOCKET 6

6 7219012 SOCKET ASSEMBLY - LIGHT 2

7 4242045 FLUORESCENT LAMP 30W F30T8/CWX 2

8 4273046 BUSHING - 3/4" SPLIT 1

9 4241124 SPRING - LIGHT DIFFUSER 2

10 7211167 THERMAL BREAK - LIGHT ASSEMBLY 1
