Model 721 Parts Manual

7210013 57

March, 2000

TABLE 30. POWER PANEL ASSEMBLY

INDEX PART NUMBER DESCRIPTION QTY

- 7211246 PWR CNTL PAN.ASSEMBLY - DOM - 120V - MEC (SEE FIGURE 28) 1

1 9989659 PCB ASSEMBLY - DUMB MECH POWR SUPPLY 1

2 7219031 HARNESS - MONETARY AC 1

3 9984629 SWITCH - TOGGLE - DPST - 20AMP 1

4 9989672 BREAKER - 15A 1

5 9989674 CIRCUIT BREAKER - 4 AMP 1

6 7211230 CONTROL PANEL - CAB.POWER 1

7 9984094 GROUND WIRE 1

8 9989046 24V XFMR - DUAL PIR. - .187 TERM. 1

9 9989100 INTERFERENCE FILTER 1

10 7219011 HARNESS - DUMB COIN MECH 1

11 7219000 HARNESS - 24V POWER 1
