Model 721 Parts Manual

7210013 59

March, 2000

TABLE 31. POWER PANEL ASSEMBLY - U.K./AUSTRALIA

INDEX PART NUMBER DESCRIPTION QTY

- 7211247 POWER CONTROL PANEL ASSEMBLY - U.K. (SEE FIGURE 28) -

1 7219000 HARNESS - 24V POWER 1

2 7219031 HARNESS - MONETARY AC 1

3 9984629 SWITCH - TOGGLE - DPST - 20 AMP 1

4 9989672 BREAKER - 15A 1

5 9989674 CIRCUIT BREAKER - 4 AMP 1

6 7211230 CONTROL PANEL - O.D. CAB. POWER 1

7 9984094 WIRE - GROUND - 14" 1

8 9989046 24V TRANSFORMER - DUAL PRI. - .187 TERM 1

9 9989100 INTERFERENCE FILTER 1

10 4279001 JUMPER - 230V - TRANSFORMER PRI 1
