Model 721 Parts Manual

7210013 61

March, 2000

TABLE 32. POWER CONTROL PANEL ASSEMBLY - 230 V - FRANCE/GERMANY

INDEX PART NUMBER DESCRIPTION QTY

1 7211248 CONTROL PANEL-230V POWER 1

2 9984627 CIRCUIT BREAKER/SWITCH - 16 AMP 1

3 9989674 CIRCUIT BREAKER - 4 AMP 1

4 9984094 WIRE - GROUND - 14" 1

5 9989046 24V XFMR - DUAL PIR. - .187 TERM 1

6 9989100 INTERFERENCE FILTER 1

7 7219000 HARNESS - 24V POWER 1

8 4279001 JUMPER - 230V - TRANSFORMER PRIMARY 1

9 7219031 HARNESS - MONETARY AC 1
