Model 721 Parts Manual
7210013 63
March, 2000
TABLE 33. REFRIGERATION ASSEMBLY, POWER CORD AND RETAINER PLATE
INDEX PART NUMBER DESCRIPTION QTY
1 7214000 REFRIGERATION MODULE 1
7214064 REFRIGERATION MODULE - INTERNATIONAL
2 9989110 FILTER - POWER LINE - EMI (230 V) 1
3 7211225 PLATE - DOM MAIN PWR CD.STR.REL. 1
4 3104056 BUSHING #SR - 7W - 2 1
5 9989776 POWER CORD - 14AWG - OUTDOOR (USA) 1
9989779 POWER CORD - AUSTRALIA - OUTDOOR (AUSTRALIA)
9989777 POWER CORD - EURO - OUTDOOR (FRANCE/GERMANY)
9989778 POWER CORD - BSI - OUTDOOR (U.K.)
6 7211165 CLAMP - MODULE 2
TABLE 34. REFRIGERATION COMPONENTS
PART NUMBER DESCRIPTION QTY
COMMON PARTS
7214008 CONDENSER 1
7214011 PAN - CONDENSATE 1
7214014 BLADE - CONDENSER FAN 1
7219002 HARNESS - COMP. 1
PARTS FOR 115 V. APPLICATIONS ONLY
4254027 GROMMET - 15/16 HEIGHT 4
4254028 SLEEVE - 55/64 LENGTH 4
4304194 DRIER 1
4304231 MOTOR - CONDENSER - 16 WATT 1
4314014 FAN - EVAPORATOR - AXIAL 1
7214000 REFRIGERATION MODULE 1
7214036 EVAP & TUBE ASSEMBLY 1
7214039 COMPRESSOR - 115V - AEA4448YXA 1
7214040 BAG - COMPRESSOR - 115V 1
PARTS FOR 230 V. APPLICATIONS ONLY
3284023 GROMMET 4
3284024 SLEEVE 4
4314054 FAN - EVAPORATOR - AXIAL - FOREIGN 1
4314089 MOTOR - CONDENSER FAN - 16W - MORILL 1
7214049 FILTER - #SKC31195-01 W/O WAFER 1
7214054 EVAP & TUBE ASSEMBLY 1
7214059 START RELAY - DANFOSS #117U6005 1
7214060 COMP. - DANFOSS - SC15G 1
7219002 HARNESS - COMP. 1
9988902 CAPACITOR - START - 80MFD - 220/250V 1
POWER CORD - 15 amp GFCI (DOMESTIC)
