Crane 721 - Page 81

Model 721 Parts Manual
7210013 77
March, 2000
TABLE 43. CABINET MOUNTED TRAY COMPONENTS
INDEX PART NUMBER DESCRIPTION
5 -
TRAY
6 -
TRAY
7 -
TRAY
1 7211223 O.D.SNACK PCB & PLATE ASSEMBLY 1 1 1
2 1596012
PCB ASSEMBLY - TRAY (PART OF INDEX 1 AND
TRAY RAIL ASSEMBLY 1571235)
567
3 7211222
PLT - O.D.SNACK PCB RAIL MOUNTIN (PART OF
INDEX 1)
111
4 1599011 HARNESS - 7 TRAY CHANNEL 1
4 1599009 HARNESS - 6 TRAY CHANNEL 1 1
5 1571229
SHIELD - TRAY RAIL/PCB (PART OF TRAY RAIL
ASSEMBLIES 1571235 AND 4971049)
567
6 1571179
TRAY GUIDE RAIL - W/STANDOFFS (PART OF
TRAY RAIL ASSEMBLY 1571235)
456
7 4971013
TRAY GUIDE RAIL ASSEMBLY. - R.H. (PART OF
TRAY GUIDE RAIL ASSEMBLY 4971049)
111
8 4971029 BRACKET - TILT STOP - TRAY - R.H. 1 1 1
- 4971028
BRACKET - TILT STOP - TRAY - L.H. (FORMED
OPPOSITE TO INDEX 8)
111
- 1571181
TRAY GUIDE RAIL ASSEMBLY - L.H. (FORMED
OPPOSITE INDEX 6 WITHOUT STANDOFFS)
456
- 1571235
TRAY GUIDE RAIL ASSEMBLY. - R.H (INCLUDES
INDEX 2, 5 AND 6).
456
- 4971026
TRAY GUIDE RAIL ASSEMBLY - L.H. - BOTTOM
(FORMED OPPOSITE INDEX 7 WITHOUT STAND-
OFFS)
111
- 4971049
TRAY GUIDE RAIL ASSEMBLY - R.H. - BOTTOM
(INCLUDES INDEX 5 AND 7)
111
1596014
