Crane 721 - Page 89

Model 721 Parts Manual
7210013 85
March, 2000
TABLE 48. WIRING HARNESSES (CONTINUED)
INDEX PART NUMBER DESCRIPTION
1 1679000 HARNESS - 5 MOTOR TRAY
2 1679001 HARNESS - 10 MOTOR TRAY
3 7219007 HARNESS - CAB.DC
4 7219002 HARNESS - COMP.
5 7219030 HARNESS - CAB/AC
6 7219018 HARNESS - POWER CORD TO PANEL
7 7219031 HARNESS - MONETARY AC
8 7219000 HARNESS - 24V POWER
9 1579008 CABLE RIBBON - 16 CONDUCTOR
10 1599009 HARNESS - 6 TRAY CHANNEL
11 7219001 HARNESS - PCB TO DISPLAY
12 1579009 JUMPER - MONETARY DOOR SWITCH
13 1679054 HARNESS - "MDB" COIN & VAL.
14 1679053 HARNESS - SERIAL VAL.
15 1679052 HARNESS - MARS PULSE VAL.
16 7219011 HARNESS - DUMB COIN MECH
17 1679051 HARNESS - MAKA PULSE
18 7219012 ASSEMBLY - LIGHT SOCKET
19 7219013 HARNESS - LIGHT ASSEMBLY
20 1679005 FILTER - 120 V
21 7219021 HARNESS - INNER DOOR SWITCH
22 7219032 SOCKET ASSEMBLY-LIGHT & SOCKET
23 7219036 NOTE: IN PLACE OF HARNESSES 7219036 AND 7219037, SOME INTERME-
DIATE CONFIGURATIONS USE A SINGLE HARNESS (7219033) BETWEEN
FILTER 1679005 AND LIGHT & STARTER SOCKETS 7219032, AND
BETWEEN FILTER 7219033 AND THE BALLASTS.
24 7219037
25 1679050 HARNESS - EXEC. COIN - LONG
26 4279001 JUMPER - 230V - TRANSFORMER PRI
27 6849015 JUMPER - POWER SW
- 1477156 JUMPER ASSEMBLY - MOTOR REVERS (NOT SHOWN)
- 1579032 HARNESS - SERIAL VALIDATOR - 24V (NOT SHOWN)
- 1579034 HARNESS FOR BA30/32SA**"MDB"** (NOT SHOWN)
- 1579050 HARNESS**MDB**FOR CONLUX 2000 (NOT SHOWN)
- 1599011 HARNESS - 7 TRAY CHANNEL (NOT SHOWN)
- 1599011 HARNESS - 7 TRAY CHANNEL (NOT SHOWN)
- 9984094 GROUND WIRE - 14” (NOT SHOWN)
- 9989718 JUMPER - VALIDATOR - 24V (NOT SHOWN)
- 9989776 POWER CORD - 14AWG - OUTDOOR - 115 V (USA) (NOT SHOWN)
- 9989777 POWER CORD - EURO - OUTDOOR (FRANCE/GERMANY) (NOT SHOWN)
1679011
1679010
