BT100
Bass Amplifier
7
System Block Diagram:
BUFFER
INPUT
-15dB PAD
LEVEL
LOW LOW
MID
HIGH
MID
HIGH
CHANNEL
SWITCH
PRE
LIMIT
POST
MUTE
EQ
NOISE
GATE
GAIN
DISTORTION
LEVEL
TUNER
A BC D EF G
SHAPE
LEVEL
OCTAVE
MASTER
BALANCED
LINE OUT
VOLUME
BALANCED
LINE OUT
GND/
GND
LIFT
EFFECTS
BLEND
EXTERNA
L
SPEAKER
SEND
HEAD
PHONES
POWER
AMP
SPEAKER
ATTENUATOR
RETURN
CD
INPUT
EFFECTS LOOP
FOOT
SWITCH
SWITCHING
CIRCUITRY

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Crate BT100 and is the answer not in the manual?

Crate BT100 Specifications

Power IconPower
output power rating100W RMS
input power requirements120 VAC, 60Hz, 115VA
Sound Specifications IconSound Specifications
gain distortion channel103dB
clean channel61dB
tone range low20dB @ 50Hz
lo mid24dB @ 150Hz
hi mid18dB @ 1kHz
high32dB @ 10kHz
signal to noise ratio65dB below full power
Inputs and Outputs IconInputs and Outputs
input impedance220k ohms
maximum input signal level accepted15 volts peak-to-peak
balanced line out jack2 volts peak-to-peak @ full rated power
Speaker Specifications IconSpeaker Specifications
internal speaker size15”
magnet56 oz.
voice coil2.5”
rms rating150 watts
impedance4 ohms
Weight and Dimensions IconWeight and Dimensions
size26-1/2” H x 21-1/2” W x 16-1/2” D
weight69 lbs
