Crate BT100 User Manual

©2003 ST. LOUIS MUSIC, 1400 FERGUSON, ST. LOUIS, MO. 63133
47-673-01 • 012904
BT100 Bass Amplifier
Output Power Rating 100W RMS 2% THD, 4Ω, 120 VAC
Gain Distortion Channel 103dB
Clean Channel 61dB
CD Inputs 33dB
Tone Range Low 20dB @ 50Hz
Lo Mid 24dB @ 150Hz
Hi Mid 18dB @ 1kHz
High 32dB @ 10kHz
Signal to Noise Ratio 65dB below full power, tones flat, gain and level @ “10”
Input Impedance 220k ohms
Maximum Input Signal Level Accepted 15 volts peak-to-peak
Balanced Line Out Jack 2 volts peak-to-peak @ full rated power w/600 ohm load
Internal Speaker Size 15”
Type Crate Custom
Magnet 56 oz.
Voice Coil 2.5”
RMS Rating 150 watts
Impedance 4 ohms
Input Power Requirements 120 VAC, 60Hz, 115VA
100/115VAC, 50/60Hz, 115VA
230VAC, 50/60Hz, 115VA
Size 26-1/2” H x 21-1/2” W x 16-1/2” D
Weight 69 lbs
BT100 T
echnical Specifications:
www.crateamps.com
Specifications subject to change without notice

Crate BT100 Specifications

Power

output power rating	100W RMS
input power requirements	120 VAC, 60Hz, 115VA

Sound Specifications

gain distortion channel	103dB
clean channel	61dB
tone range low	20dB @ 50Hz
lo mid	24dB @ 150Hz
hi mid	18dB @ 1kHz
high	32dB @ 10kHz
signal to noise ratio	65dB below full power

Inputs and Outputs

input impedance	220k ohms
maximum input signal level accepted	15 volts peak-to-peak
balanced line out jack	2 volts peak-to-peak @ full rated power

Speaker Specifications

internal speaker size	15”
magnet	56 oz.
voice coil	2.5”
rms rating	150 watts
impedance	4 ohms

Weight and Dimensions

size	26-1/2” H x 21-1/2” W x 16-1/2” D
weight	69 lbs
