7
7
System Block Diagram:
EFFECTS
SEND
EFFECTS
RETURN
BRIGHT
EQ
INPUT
INPUT
BUFFER
GAIN
ONE
GAIN
SELECT
CHANNEL
SELECT
GAIN
TWO
LEVEL
LOW
MID
HIGH
EQ
LOW
MID
HIGH
SPEAKER
OUTPUT
POWER
AMP
SPEAKER
OUTPUT
CHANNEL A
CHANNEL A
CHANNEL A
CHANNEL B
CHANNEL B
CHANNEL B
REVERB
CH.A
REVERB
CH.B
REVERB
SEND
REVERB
PAN
GX-900H/GX-2200H Guitar Amplifiers
by
GX-900H/GX-2200H Guitar Amplifiers
by

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Crate EXCALIBUR GX-2200H and is the answer not in the manual?

Crate EXCALIBUR GX-2200H Specifications

GX-900H

Power IconPower
input power requirements120VAC, 60Hz, 240 watts max.
output power rating90 watts RMS @ 5% THD, 2 ohm load
fuse rating and type2A Normal Blo, 250V Internal, 100VAC-120VAC; 1A Slo Blo, 250V Internal, 230 VAC
Audio Specifications IconAudio Specifications
maximum input signal level accepted8 volts peak to peak
input impedance470 k ohms
total system gain, channel B54 dB @ 1 kHz, all controls at “10”, Bright off
total system gain, channel A, gain one69 dB @ 1 kHz, all controls at “10”
total system gain, channel A, gain two86 dB @ 1 kHz, all controls at “10”
Weight and Dimensions IconWeight and Dimensions
cabinet size11.63” H x 30.75” W x 11” D
weight35 lbs.

GX-2200H

Power IconPower
input power requirements120VAC, 60Hz, 500 watts max.
output power rating220 watts RMS @ 5% THD, 2 ohm load
fuse rating and type5A Normal Blo, 250V Internal, 100VAC-120VAC; 3A Normal Blo, 250V Internal, 230VAC
Audio Specifications IconAudio Specifications
maximum input signal level accepted8 volts peak to peak
input impedance470 k ohms
total system gain, channel B54 dB @ 1 kHz, all controls at “10”, Bright off
total system gain, channel A, gain one69 dB @ 1 kHz, all controls at “10”
total system gain, channel A, gain two86 dB @ 1 kHz, all controls at “10”
Weight and Dimensions IconWeight and Dimensions
cabinet size11.63” H x 30.75” W x 11” D
weight35 lbs.
