Crate EXCALIBUR GX-2200H User Manual

Technical Specifications:
Maximum Input Signal Level Accepted 8 volts peak to peak
Input Power Requirements GX-900H: 120VAC, 60Hz, 240 watts max.
GX-2200H: 120VAC, 60Hz, 500 watts max.
Input Impedance 470 k ohms
Total System Gain Channel B: 54 dB @ 1 kHz, all controls at “10”, Bright off
Channel A: Gain One: 69 dB @ 1 kHz, all controls at “10”
Gain Two: 86 dB @ 1 kHz, all controls at “10”
Output Power Rating GX-900H: 90 watts RMS @ 5% THD, 2 ohm load
GX-2200H: 220 watts RMS @ 5% THD, 2 ohm load
Channel B Low 25 dB range @ 70 Hz
Mid 14 dB range @ 800 Hz
High 29 dB range @ 10 kHz
Bright 7 dB boost @ 10 kHz
Channel A Low 18 dB range @ 100 Hz
Mid 10 dB range @ 1 kHz
High 17 dB range @ 6 kHz
Fuse Rating and Type GX-900H: 2A Normal Blo, 250V Internal, 100VAC-120VAC; 1A Slo Blo, 250V Internal, 230 VAC
GX-2200H: 5A Normal Blo, 250V Internal, 100VAC-120VAC; 3A Normal Blo, 250V Internal, 230VAC
Cabinet Size and Weight: 11.63” H x 30.75” W x 11” D
35 lbs.
The GX-900H and GX-2200H are covered with a durable black Tolex material; wipe them clean with a damp lint-free cloth to remove dirt and road film.
Never spray cleaning agents directly onto the cabinets, and stay away from abrasive cleaners which could damage their finish.
CRATE/SLM ELECTRONICS, A DIVISION OF ST. LOUIS MUSIC, 1400 FERGUSON AVENUE, ST. LOUIS, MO 63133
47-590-01 • 07-95
CRATE continually develops new products, as well as improves existing ones. For this reason,
specifications and information in this manual are subject to change without notice.
