Page #3 background image
Turntable data cable
MICRO USB
Plug
to fix the angle
> Mounting the scanner to the set screws
Adjust the tripod height and rotate the height locking ring to lock>
> Open the tripod as shown in the top picture, rotate the tripod stabilizer ring
> Adjust the scanner angle and tighten the universal ball joint screw to lock
Universal ball joint
Height adjustment
locking ring
Height adjustment
Tripod Stabilizer Ring
Upgrade kit
Turntable Mode (Tripod)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Creality CR-Scan 01 and is the answer not in the manual?

Creality CR-Scan 01 Specifications

General IconGeneral
Scan Accuracy0.1 mm
Scan Speed10 fps
Light SourceWhite light
Output FormatsOBJ, STL
ConnectivityUSB
TechnologyStructured Light
Resolution0.5 mm
Operating System CompatibilityWindows
Scanning Area200 x 200 mm
Working Distance400mm - 900mm
CompatibilityWindows
Power SupplyDC 12V
AlignmentFeature/Marker/Manual
