11ENGLISH
I J
CHOICE OF HEIGHT
++
Using a screwdriver, remove the two screws on the bar tilt
bracket I.
Remove the pin from the tilt
bracket.
Carefully remove the pin
from the bar I.
Attach the tilt bracket to
the bar J.
Place the pin of the tilt sup-
port on the bar J.
Remove the tilt bracket
from the bar I.
Pull out the bar pin locking
piece I.
Slide the tilt stand down.
Before you start, choose the desired height.
(10cm+/-)
You will have to choose between the height of the
piece I wave J.
· If you choose the height of the piece J, You must
follow the instructions below.
· If you choose the height of the piece I, go directly
to step 2 (page 12).
1
4
7 8 9
2
5
3
6
TILT SUPPORT
I
I
J J
J
