16 ENGLISH
Select and connect the
ground cables, including
the one for your installation.
You will need to attach the
remaining wires from the
piece B and the phase and
neutral cables of its instal-
lation in the strip of the
piece O, as it's shown in the
following.
Once connected, place the
pieces O screwing them
until they are secure.
7 8 9
O
Connect the LINE cable
of the driver (AC-L) to the
PHASE cable of your instal-
lation.
Connect the NEUTRAL ca-
ble of the driver (AC-N) to
the NEUTRAL cable of your
installation.
Make sure no wires are
pinched.
10 11 12
Slide piece A upwards to t it on the protruding screws of
the piece K.
Once tted, turn the piece A
to the right.
13 14 15
K
K
A
To Next Page
