Using Your Player 4-20
Depending on which EQ setting you want, follow the corresponding step:
To select Rock, Pop, Classical, Jazz or Normal
Scroll Select the EQ setting you want.
The selected EQ icon appears on the screen.
To define your own EQ settings
1. Scroll Select the Custom EQ icon
(Figure 4-61).
The Custom EQ screen (Figure 4-62)
appears.
2. Five vertical control levers will appear in the
display. Each lever represents successively
higher frequencies that can be controlled. 62
Hz controls bass frequency, 250 Hz adjusts
the low mid-range frequency, 1 kHz adjusts
the mid-range frequency, 4 kHz adjusts the
upper mid-range frequency and 16 kHz
adjusts the treble frequency.
3. Scroll Select each vertical control level. Use the Scroller to move the
control knob up or down to vary the amount of boost or reduction in the
selected frequency range.
4. Scroll Select the check mark to exit the Custom EQ screen.
Figure 4-61
Figure 4-62
