General Specifications A-4
SB1394 Interfaces
❑
One 2 x 5 pin Internal SB1394 connector (J6) on card for connection to the Audigy
Extension card
❑
One 6-pin SB1394 connector/port on rear bracket
Interfaces
❑
VOL_CTRL 1 x 4 pin header
❑
PC_SPK (PC speaker) 1 x 2 pin header
❑
AUD_EXT 2 x 20 pin header for connection to Audigy Drive
❑
JOYSTICK 2 x 8 pin header for connection to the Joystick/MIDI connector (metal
bracket attachment provided but optional)
The 6-pin SB1394
connector/port has a 2 watt
maximum power output.
Connect only one high power
usage device such as the
IEEE 1394 hard disk and CD-
RW drive to this port unless
it is self-powered.
