General Specifications
High Definition Audio Quality (for Windows)
l 24-bit Digital-to-Analog conversion of digital sources during playback in 24-bit with sampling rate of
up to 44.1 kHz.
l 16-bit Analog-to-Digital conversion of analog sources during recording in 16-bit with sampling rates
up to 44.1 kHz.
Inputs
l One 3.5 mm (1/8") jack for mono analog microphone input
l One 3.5 mm (1/8") jack for stereo line-level analog input
l One Micro-USB port
l Built-in mono microphone
Outputs
l Two 3.5 mm (1/8") jack for stereo analog headphones
l Up to 600 ohm headphone amplifier
Controls and Indicators
l Multifunction button
l Volume control
l Power button
l White/Red LED for power/battery indication
Physical Specifications
l Dimensions (L x W x H) : 35 x 19 x 66 mm
l Weight: Approx. 0.025 kg
Technical Specifications
l Operating Temperature range: 0°C to 40°C (32°F to 104°F)
l Lithium Ion Battery: 3.7 V 200 mAh (0.74 Wh)
l USB Input: 5V 500mA
Sound Blaster E1 – General Specifications 28
