AbouttheDINJack
YourX-FiI/OConsole*featuresaDINjackonitsrearpanel.Inordertoenjoy
integratedspeakercontrolfunctions,youcanconnectthisjacktoselected
CreativeanalogspeakersystemsthathaveawiredremotecontrolorAudio
ControlPod.
Youcan,forexample,adjustthevolumeofyourspeakers,ormutethem,using
theMasterVolume/MutedialonyourX-FiI/OConsole.
Jack,ConnectororCable
1. DINjack
2. 9-pinDINcable
3. DINjack,oftenlabelledasVolumeControl
Notes
*Availablewithsomemodelsofyouraudiodevice,orasanupgrade
accessoryinsomeregions.
