Creative Sound Blaster X-Fi - I;O Drive and Console Connectivity; I;O Drive and Console Connections

OpticaljackforopticalSPDIFoutput
CoaxialjackforcoaxialSPDIFoutput
SoundBlasterX-FiI/ODrive*
Inputsandoutputsonfrontpanel
TwoRCAjacksforcoaxialSPDIFinputandoutput
Headphoneoutputandvolumecontrolwithautodetectionvia6.35mm(1/4-
inch)stereojack
Sharedline-levelanalogLine/Microphoneinputvia6.35mm(1/4-inch)stereo
jack.Sharedinputselectableviadialwithgaincontrolformicrophone.
TwominiMIDIfemaleconnectorsforMIDIinputandoutput
TwoRCAjacksforAuxiliaryinput
TwoopticalconnectorsforopticalSPDIFinputandoutput
Infraredreceiverforreceivinginfraredsignalsfromtheremotecontrol.
Transmissionrangewithinfourmeters(13feet)with15-degreedeviationfrom
thecenteraxis.
Interfaces
4-pinpowersupplyheaderforconnectiontosystempowersupplyunit
2x20pinAD_EXTheaderforconnectiontoSoundBlasterX-Fiaudiocard
SoundBlasterX-FiI/OConsole*
Inputsandoutputsonfrontpanel
Headphoneoutputandvolumecontrolwithautodetectionvia6.35mm
(1/4-inch)stereojack
Sharedline-levelanalogLine/Hi-Zinputvia6.35mm(1/4-inch)stereojack.
SharedinputselectableviadialwithgaincontrolforHi-Zinput.
Sharedline-levelanalogLine/Microphoneinputvia6.35mm(1/4-inch)stereo
jack.Sharedinputselectableviadialwithgaincontrolformicrophone.
Infraredreceiverforreceivinginfraredsignalsfromtheremotecontrol.
Transmissionrangewithinfourmeters(13feet)with15-degreedeviationfrom
thecenteraxis.
Inputsandoutputsonrearpanel
