Connectivity
SoundBlasterX-Fiaudiocard
AudioInputs
Oneanaloginputviastereojackonrearbracket(selectablefromline-level
analoglineinputormonomicrophoneanaloginput)
AUX_INline-levelanaloginputvia4-pinMolexconnectoroncard
AudioOutputs
Threeline-levelanalogoutputsvia4-pole3.50mm(1/8-inch)jacksonrear
bracket:FrontLeft,FrontRight,RearLeft,RearRight,SideRight,Center,
SubwooferandSideLeftchannels
Stereoheadphone(32-ohmload)supportonLineOut1jack
ForSB046XandSB055Xseries:DigitalOutvia3.50mm(1/8-inch)jackon
rearbracket(sharingwiththeLineIn/MicrophoneInjack)
ForSB073Xseries:OpticalOutvia3.50mm(1/8-inch)jackonrearbracket
(sharingwiththeLineIn/MicrophoneInjack)
Interfaces
4-pinpowersupplyheaderforconnectiontothesystempowersupplyunit,
supplyingpowertotheX-FiI/OConsole*
2x20pinAD_EXTheaderforconnectiontotheX-FiI/ODrive*
2x5pinFrontPanelHeaderforconnectionswithIntelHDFrontPanelAudio
standardheader(ForSB073Xseriesonly)
OneAD_Link(26pin)connectorforlinkingtotheX-FiI/OConsole*
DigitalI/OModule*
AudioInputs
OpticaljackforopticalSPDIFinput
CoaxialjackforcoaxialSPDIFinput
AudioOutputs
