14
2. Push the emission tool and keeping it pushed place the emission filter in it as shown in figure below
(every manufacturer has its proper way to place the filter in the optical path so follow manufacturer
instructions in order to mount them correctly.)
3. Release the tool in order to grab the filter in steady position
