q – Query State of All Devices
Format q<CR>
Return Value q <B’N’><C’N’><D’N’><N’N’> <CR>
Examples q<CR> B1C1D1N1<CR>
r – Read Current Position of Individual Device
Format r<device ID><CR>
Parameters <device ID> ID assigned to a device (see table on page 1)
<position> Current position or state
Return Value r<device ID><position><CR>
Examples rC<CR> rC1<CR> The dichroic filter wheel is in position 1.
rD<CR> D1<CR> Disk 40um
rB<CR> B1<CR> emission wheel1
rN<CR> N1<CR> Disk on
v – Read Firmware Version
Format v<CR>
Parameters <version> version of touch screen firmware
Return Value v< version ><CR>
Examples v<CR> Ver. 2.0.1.<CR>
The firmware version is reported as Ver. 2.0.1.
