30 • TSS-70 Series Product Manual — Doc. 8745H
Viewing Angle ±80° horizontal, ±80° vertical
Touch Screen Projected capacitive, 5-point multitouch capable
Buttons
Virtual Buttons (6) Virtual buttons in collapsible universal tool bar, per-button show/hide,
preconfigured with icons for Power, Home, Lights, Up, Down, and Microphone
Reset Pin hole on rear panel for hardware reset
Audio
Features Built-in speakers for touch feedback and alerts
Connectors
LANPoE (1) 8-pin RJ-45 connector, female, with 2 LEDindicators;
100BASE-TX Ethernet port;
PoE+ PD port;
Green and yellow LEDs indicate Ethernet port status
USB (2)USB Type-Aconnectors, female;
USB 2.0 host ports;
For optional room scheduling accessories
NOTE: The touch screen supports the use of a single light bar or status indicator accessory only. The RFID-
USBcard reader accessory can be connected to the second USBport.
Power
PoE(Power over Ethernet) IEEE 802.3at Type 2 compliant PoE+ PD (Powered Device);
Requests 15 W from an 802.3at Type 2 PSE with LLDP advanced power management;
Requests 30 W (PoE+Class 4) from an 802.3at Type 2 PSE without LLDP;
Requests 15.4 W (PoEClass 0) from an 802.3af (or 802.3at Type 1)PSE
Environmental
Temperature 32 to 104°F (0 to 40°C)
Humidity 10% to 95%RH (noncondensing)
Heat Dissipation 44BTU/hr
