Product Manual — Doc. 8745H TSS-70 Series • 5
NOTE: The touch screen supports the use of a single light bar or status indicator accessory only. The
RFID-USBcard reader accessory can be connected to the second USBport.
l
The optional TSW-770-LB series light bars provide a 180° visual indication of a room’s availability
status, illuminating green if the room is available and red when reserved, with options for custom
color mixing and programming.
4
l
The optional SSW-EL and SSC-EL series hallway signs feature a twosided acrylic sign face that
can be custom engraved with the room name or number. The SIW-100 offers a lower profile wall
mount status indicator.
4
Bluetooth Beacon
The built-in Bluetooth® proximity detection beacon works with the Crestron Go App and Crestron App
to determine when a mobile device is in or near the same room as the beacon, and signals the mobile
app to automatically display the appropriate controls and information for the room.
5
Proximity Sensor and Brightness Controls
The TSS-770 provides abuilt-in proximity sensor that wakes the screen without requiring any user
interaction, and automatic brightness controls ensure optimal visibility under varying lighting conditions.
Power over Ethernet
PoE (Power over Ethernet) eliminates the need for a local power supply or any dedicated power wiring.
Crestron PoE switches (sold separately) offer a total networking solution with built-in PoE for multiple
touch screens. A PoE Injector (PWE-4803RU, sold separately) is also available to support a single touch
screen.
NOTE: Refer to the “Power” specifications for more details.
XiOCloud Service
The TSS-770 is compatible with the XiO Cloud® service, which remotely provisions, monitors, and
manages Crestron devices across an enterprise or an entire client base. Built on the Microsoft® Azure®
software platform and utilizing Microsoft's Azure IoT Hub technology, XiO Cloud enables installers and
IT managers to deploy and manage thousands of devices simultaneously. Unlike other virtual
machine-based cloud solutions, Azure services provide unlimited scalability. For more information, visit
www.crestron.com/xiocloud.
Wall Mount Options
Using the bracket provided, the TSS-770 is easily installed over a 2-gang or 3-gang US electrical box, or a
2-gang European or UK electrical box. A security latch option is included to deter unauthorized removal
of the touch screen.
Additional wall mounting options are available using the optional TSW-UMB-70 universal mounting
bracket, TSW-UMB-70-PMK preconstruction mounting kit, and TSW-UMB-70-BBI back box (sold
separately).
