Remote Temperature/Humidity Sensor Crestron C2N-RTHS
with a 2-Series control system upgrade file (CUZ) version prior to 3.008,
but can be used with later versions of firmware and requires that a single
unit be the only network device connected to the control system.
Method B (Touch Settable IDs), which begins on the next page, applies to
C2N-RTHSs in a Cresnet system with 2-Series control system upgrade
file (CUZ) version 3.029 or later. These upgrades enable Touch Settable
ID (TSID) functionality, which makes it possible for the control system to
recognize a network device via its serial number, which is stored in the
device’s memory. This method does not require that any devices be
disconnected from the network; Net IDs may be set with the entire
Cresnet system intact. This method requires the use of the Crestron
Viewport version 3.35 or later.
Use the appropriate method to set the C2N-RTHS Net ID.
Method A (Cresnet address-settable ID)
1. Ensure that the C2N-RTHS is the only device connected to the
control system.
2. Open the Crestron Viewport.
3. From the Viewport menu, select Functions | Set Network ID.
The software checks the baud rate and then opens the "Set
Network ID" window.
4. In the "Set Network ID" window, select the C2N-RTHS from
the Current Network Devices text window.
5. Select the new Net ID for the C2N-RTHS from the Choose the
new network ID for the selected device (Hex): text box.
6. Click Set ID to initiate the change. This will display the "ID
command has been sent" window.
7. In the "Command Complete" window, click OK.
8. In the Current Network Devices text window, verify the new
Net ID code.
9. In the "Set Network ID" window, click Close.
NOTE: The new Net ID code may also be verified by selecting
Diagnostic | Report Network Devices in the Viewport (alternately, select
F4).
8 • Remote Temperature/Humidity Sensors Operations & Installation Guide – DOC. 6232A
