Crestron C2N-RTHS Remote Temperature/Humidity Sensor
C2N-RTHS Digital Input and Analog Output Signals
Signal Analog/Digital Function Value
TempInDegreesC Digital Determines
temperature output
units
1 = Degrees
Celsius
0 = Degrees
Fahrenheit
Temp Analog
(signed)*
Temperature in
tenths of a degree
(ex. 723 = 72.3°F)
-400 to 1760 °F
-400 to 800 °C
Humidity Analog Relative Humidity
in percent
(ex. 52 = 52%)
0 to 100
* To display negative numbers for TPS panels, check “Signed Feedback” on the
Design tab in the VT Pro-e “Object Properties” window. On other panels, such as the
CT-1000, Crestron recommends converting the signed number to a display string if
you expect the temperature to be negative.
Uploading and Upgrading
NOTE: Crestron recommends that you use the latest software and that
each device contains the latest firmware to take advantage of the most
recently released features. Please check the Crestron website
(http://www.crestron.com/updates) for the latest versions of software and
firmware. New users are required to register to obtain access to this site.
Assuming a PC is properly connected to the entire system, Crestron
programming software allows the programmer to upload programs and
projects after their development to the system and network devices.
However, there are times when the files for the program and projects are
compiled and not uploaded. Instead, compiled files may be distributed
from programmers to installers, from Crestron to dealers, etc. Even
firmware upgrades are available from the Crestron website as new
features are developed after product releases. In those instances, one has
the option to upload via the programming software or to upload and
upgrade via the Crestron Viewport.
Operations & Installation Guide - DOC. 6232A Remote Temperature/Humidity Sensor • 15
