Crestron CLW-DIM1/4RF, -DIMS1/4RF, -SLVD1RF infiNET™ Dimmers
infiNET Dimmer Troubleshooting (continued)
TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION
If the LED flashes OFF for
¼ second two times, then
returns to low, the MNET ID
of device is not set to match
the MNET ID of the SIMPL
Windows program.
Using Crestron Toolbox, poll
the network. Verify that the
MNET ID for the infiNET
device is set to match the
MNET ID specified in the
SIMPL Windows program.
If the LED flashes OFF for
¼ second four times, then
returns to low every eight
seconds, the infiNET device
is not transmitting data to
the C2N-MNETGW.
Open Crestron Toolbox and
select the Network Device
tree. Expand the network
device tree until the gateway
to be managed is selected.
Right-click the Net ID of the
selected gateway to open the
sub-menu and select
Functions|MNET
Gateway…. If devices are not
listed, add devices by putting
the C2N-MNETGW and
infiNET device in Acquire
mode.
Dimmer
presses are
not reported
to control
system.
Dimmer is attached to load
and the signal
Enable_Local_Btn_Outputs
is low.
In the dimmer symbol of the
SIMPL Windows program, set
the signal
Enable_Local_Btn_Outputs
high.
Dimmer
does not
operate as
described in
the manual.
Dimmer is detached from
the load.
In the dimmer symbol of the
SIMPL Windows program, set
the signal Detach_Load low.
Mode selection switch is in
the incorrect position.
Set the mode selection switch
to the “SET” position to store
presets.
Presets will
not store.
Trying to store Preset 1 or
Preset 2 when the load is at
0% (Off)
Set load to higher level.
Cannot
recall preset
light settings.
Mode selection switch is in
the incorrect position.
Set the mode selection switch
to the “RUN” position to recall
presets.
Slave device
does not
emulate the
RUN mode
of the
-DIMS1RF
(even when
connected to
–DIMS4RF).
-SLVD1RF is detached from
the load.
Set the signal
Detach_Load_From_Slave
low.
Bootloader
In rare cases, it may be necessary to bypass the dimmer’s standard firmware and
enter into the “bootloader”. This might be necessary if the unit was loaded with a
faulty version of firmware that might prevent future firmware upgrades.
Operations Guide - DOC. 6396 infiNET Dimmers: Crestron CLW-DIM1/4RF, -DIMS1/4RF, -SLVD1RF • 37
